e-CAM21_CURZ - Sony® STARVIS™ IMX462 Ultra Low-Light Camera for Renesas RZ/V2L

Highlights

  • Houses - Full HD Sony® Starvis™ Camera Module with S-mount lens holder
  • Ultra low light performance
  • Plugs directly into the Renesas RZ/V2L development kit
  • On-board high performance ISP

SAMPLE PRICE

Excluding Shipment Charges

Documents

Supported Platforms,

e-CAM21_CURZ is a Full HD custom lens camera module based on 1/2.8" Sony Starvis IMX462 CMOS image sensor. It is a color camera which supports UYVY image format and provided with S-mount (also known as M12 board lens) lens holder.

e-CAM21_CURZ can be interfaced to the CN1 connector of the Renesas RZ/V2L development kit. e-CAM21_CURZ stands out in its superior near-infrared performance. The high sensitivity of this camera helps to capture images in as extreme low lighting conditions as 0 lux, which makes it suitable for night vision applications and medical microscopes.

Refer pdfDatasheet for complete frame rate details.

  • Key features:
    • Frame Rate:
      • Streams HD at 60 fps, FHD at 60 fps
      Refer pdfDatasheet for more details.
    • Output format: Uncompressed UYVY format
    • High speed 4-lane MIPI CSI-2 interface
    • Standard M12 lens holder for use with customized optics or lenses for various applications
    • Lightweight, versatile, and portable design
  • Interface:
    • Interface: 4-Lane MIPI CSI-2
    • Connector: 24pin FPC connector
    • Cable length: 30cm
  • Module features:
    • Sensor: IMX462 from Sony® Starvis™
    • Focus Type: Fixed focus
    • Sensor Resolution: Full HD
    • Chroma: Color
    • Shutter Type: Rolling Shutter
    • Optical Format: 1/2.8"
    • Output Format: Uncompressed UYVY
    • Pixel Size: 2.9μm x 2.9μm
    • Sensor Active Area: : 1920H x 1080V
    • Array Size: : 1920H x 1080V
    • G Sensitivity: 2376mV for HCG mode; 921mV for LCG mode
    • Holder: M12 (S-Mount)
    • DFOV: 132°(D), 113°(H), 61°(V) (with the lens provided by e-con)
  • Electrical and Mechanical:
    • Operating Voltage: 3.3V with +/- 5%
    • Operating Temperature Range: -30°C to 70°C
    • Typical power consumption: - 1.31W
    • Size in mm (l x b): 30 x 30 mm
  • Miscellaneous:
    • Compliance: RoHS
  • e-con Systems provides the sample applications that demonstrates the features of this camera. However, this camera can also be utilized by any V4L2 application.
  • Linux camera driver:
    • V4L2 Linux driver for MIPI CSI-2 camera module:
      • Video preview
      • Still Image capture
      • Camera controls via IOCTLs
  • Please contact camerasolutions@e-consystems.com for any customization requirements.
 Bullat Arrow  Datasheet
 Bullat Arrow  User Manual

Download Full HD Camera Documents

Processor Carrier Board Sample Price
(1 Unit)
RZ/V2L
Renesas RZ/V2L development kit
RZ/V2L
RZ/V2L on MistyWest Carrier Board
RZ/G2L
RZ/G2L on MistyWest Carrier Board

RZ/V2L-Renesas RZ/V2L development kit

Sample Price (1 Unit)--

contact us

RZ/V2L-RZ/V2L on MistyWest Carrier Board

Sample Price (1 Unit)--

contact us

RZ/G2L-RZ/V2L on MistyWest Carrier Board

Sample Price (1 Unit)--

contact us



Kit Contents
  • Full HD Sony Starvis™ Camera Module with Lens
  • Adaptor board
  • FPC cable (15cm)
  • Camera and features customization based on specific requirements. Please contact camerasolutions@e-consystems.com for customization requirements.

Targeted Applications
