e-CAM314_CUMI0341C_MOD - 3MP AR0341AT 150dB HDR Camera Module


  • Houses AR0341AT Image Sensor from onsemi®
  • Super-exposure pixel technology
  • 150dB High Dynamic Range (HDR) + LFM

Samples Price


Evaluate e-CAM314_CUMI0341C_MOD with,

The e-CAM314_CUMI0341C_MOD is a 3MP camera module featuring the AR0341AT image sensor from onsemi®. This module stands out with its remarkable features, including super-exposure pixel technology that provides 150 dB high dynamic range (HDR) with LED flicker mitigation (LFM) operation. This super-exposure pixel technology eliminates the need for auto exposure control operations and also minimizes latency in sensing and viewing camera applications, making it highly suitable for Advanced Driver Assistance Systems (ADAS) and other critical applications.

The e-CAM314_CUMI0341C_MOD camera module also comes equipped with an on-board high-performance ISP, further enhancing image processing capabilities. It offers versatile interface options, supporting GMSL and MIPI, providing seamless integration capabilities for a wide range of applications.

  • Key features:
    • Frame Rate: 3MP @ 60 fps
    • Output Format - RAW Bayer
    • High-speed MIPI CSI-2 interface
    • S-mount interchangeable lens holder for flexibility to choose a lens as per application requirements
    • Small form-factor
  • Sensor features:
    • Sensor: AR0341AT from onsemi®
    • Focus Type: Fixed focus
    • Sensor Resolution: 3MP
    • Chroma: Color
    • Shutter Type: Electronic Rolling shutter
    • Optical Format: 1/3.6"
    • Output Format: RAW Bayer
    • Pixel Size: 2.1 μm x 2.1 μm
    • Sensor Active Area: 1920 (H) x 1536 (V)
    • Array Size: 1920 (H) x 1536 (V)
    • Holder: M12 (S-Mount)
    • FOV: TBD
  • Electrical & Mechanical:
    • Operating Voltage: 3.3V ±5%
    • Operating Temperature Range: -40°C to 80°C
    • Typical power consumption:TBD
    • Size in mm (l x b): 30 x 30 mm
  • Miscellaneous:
    • Compliance: RoHS
 Bullat Arrow  Download e-CAM314_CUMI0341C_MOD Documents

Download Full HD USB Camera Documents

Supported Platforms SAMPLE PRICE
(1 Unit)
NVIDIA Jetson AGX Orin / Xavier
NVIDIA Jetson Orin NX / Orin NANO ContactUs


Customers interested in customizing the same camera module or planning to use a different camera/sensor module can contact camerasolutions@e-consystems.com and explain their requirements.

e-CAM314_CUMI0341C_MOD - Customization for other Application Processor platforms:

e-con provides customization for this e-CAM314_CUMI0341C_MOD on any application platform as per customer requirements.

e-CAM314_CUMI0341C_MOD Customization:

e-con provides customization for the following requirements:

  • PCB form-factor customization for any shape, connector and orientation
  • Lens holder customization for C/S mount lens holder
  • Supported platforms: NXP i.MX8 Series, NVIDIA Jetson Platforms, Qualcomm QRB5165 and other processor
  • Camera and features customization based on specific requirements. Please contact camerasolutions@e-consystems.com for customization requirements.

Targeted Applications

  • ADAS

  • Automated Guided Vehicle (AGV)

  • Automotive Grade Dash Cam

  • Robot Delivery

  • Autonomous vehicles
