NileCAM25_CUQRB5 - FullHD GMSL2 Global Shutter Camera for Qualcomm® Robotics RB5 Vision Kit

Highlights:

  • Houses NileCAM25 - AR0234 GMSL2 Camera Module
  • Global Shutter
  • Plugs into Qualcomm® Robotics RB5 Vision Kit
  • Gigabit Multimedia Serial Link 2 (GMSL2) interface with FAKRA connector
  • Shielded coaxial cable to transmit power and data up to 15m
  • On-board high performance ISP
  • Optional IP67-rated enclosure

Sample Price

Documents

Supported Platforms,

NileCAM25_CUQRB5 is a Full HD global shutter GMSL2 color camera for Qualcomm® Robotics RB5 processor.

This camera kit consists of NileCAM25, a 2MP global shutter camera module based on onsemi AR0234 sensor. This global shutter camera captures Full HD images at a high frame rate, which helps to minimize frame-to-frame distortion and reduce motion blur while capturing fast-moving objects to produce crystal clear images with greater scene details.

Also, this multi-camera solution allows the connection of up to two NileCAM25 cameras and enables synchronized Full HD streaming simultaneously.

Refer pdfDatasheet for complete frame rate details.

  • Key features:
    • Frame Rate:
      • Streams 1080p @ 60fps
      Refer pdfDatasheet for complete frame rate details.
    • Output format: YUV422
    • S-mount lens holder for flexibility to choose a lens as per application requirements
    • Lightweight, versatile, and portable design
  • Interface:
    • Interface: GMSL2
    • Connector: FAKRA connector
    • Cable Length: 15m
  • Sensor features:
    • Sensor: AR0234CS from onsemi®
    • Focus Type: Fixed focus
    • Sensor Resolution: Full HD
    • Chroma: Color
    • Shutter Type: Global Shutter
    • Optical Format: 1/2.6"
    • Output Format: Uncompressed YUV422
    • Pixel Size: 3μm x 3μm
    • Sensor Active Area: 1920(H) x 1200(V)
    • Array Size: 1920(H) x 1200(V)
    • Responsivity: 56 Ke-/luxsec
    • SNR: 38 dB
    • Dynamic Range: 71.4 dB
    • Holder: M12 (S-Mount)
    • FOV: 128.2 °(D), 104.6°(H), 61.6°(V) (with the lens provided by e-con)
  • Electrical & Mechanical:
    • Operating Voltage: 5 to 15V with +/- 5% tolerance
    • Operating Temperature Range: -30°C to 70°C
    • Typical power consumption: TBD
    • Size in mm (l x b): 30 x 30 mm
  • Miscellaneous:
    • Compliance: RoHS
  • Launched on: launching date
  • gstreamer based camera application for:
    • Dual camera streaming over Ethernet and WIFI (H.264 encoded)
    • HDMI streaming (NV12)
    • Snapshot image capture in JPEG and RAW Bayer
    • H.264 and H.265 encoded video recording
  • Camera Controls:
    • Gamma
    • Denoise
    • Gain
    • Exposure etc.
  • Please contact camerasolutions@e-consystems.com for any customization or porting of camera driver to your requirements.
 Bullat Arrow  Datasheet

Download Full HD GMSL2 Camera Documents

NileCAM25_CUQRB5 - Customization for other Application Processor platforms:

e-con Systems™ provides camera driver development, customization and porting services for NileCAM25_CUQRB5 on any application platform as per customer requirements.

NileCAM25_CUQRB5 - Customization:

e-con provides customization, development and porting services for the following requirements:

  • IP rated (IP67) enclosure and IP rated (IP67) cables for rugged applications
  • Length of the co-axial cable
  • Change of lens to meet your FOV and other requirements
  • Support for other processor platforms
  • Camera and features customization based on specific requirements. Please contact camerasolutions@e-consystems.com for customization requirements.
