e-CAM22_CUNX - Sony® STARVIS™ IMX462 Ultra Low-Light Camera

e-CAM22_CUNX is a Full HD ultra-lowlight MIPI camera for NVIDIA® Jetson Xavier™ NX developer kit. This ultra-low light camera is based on SONY STARVIS™ IMX462 color CMOS image sensor. This camera can be directly connected with NVIDIA® Jetson Xavier™ NX developer kit.

e-CAM22_CUNX stands out in its superior near-infrared performance. The high sensitivity of this camera helps to capture images in as extreme low lighting conditions as 0 lux, which makes it suitable for night vision applications and medical microscopes.

  • Houses e-CAM221_CUMI462_MOD - Full HD Sony Starvis™ Camera Module with S-mount lens holder
  • High-speed MIPI CSI-2 interface to connect with the CPU
  • Plugs in to NVIDIA® Jetson Xavier™ NX development kit
  • Uses NVIDIA® Internal Image Signal Processor (ISP) for image processing
  • Frame Rate:
  • Resolutions YUV (NV12)
    HD (1280 x 720) 60 fps
    FHD (1920 x 1080) 30 fps & 60fps
  • Operating Voltage : 3.3V +/- 5%
  • Operating Temperature Range : -30°C to 85°C
  • Typical Power Consumption : 0.495 W
  • Customized LibArgus application for multicamera streaming, image capture and video recording
  • Gstreamer-1.0 support for video recording and network streaming
  • Dimension ( L x W ): 30 mm x 30 mm
  • Lightweight, versatile, and portable multi-board solution
  • RoHS compliant
  • Launched on:launch date

Sensor:1/2.8" Optical format CMOS Image sensor

Focus Type:Fixed focus

Resolution:Full HD


Pixel size:2.9 μm x 2.9 μm

Sensor Active Area:1937H x 1097V

Output Format:RAW 12 bit

Shutter type:Electronic Rolling Shutter


Array Size:1937 x 1097 Pixels

DFOV :Full HD - 121.35° (with the lens provided by e-con)

Linux camera driver:

Full-fledged Linux camera driver for MIPI CSI-2 camera module. The driver supports e-con's e-CAM22_CUNX on NVIDIA® Jetson Xavier™ NX developer kit

  • Supported Jetpack & L4T Version
    • NVIDIA® Jetson Xavier™ NX - Jetpack 5.1.2 L4T 35.4.1
  • V4L2 Linux driver for MIPI CSI-2 camera module
    • Video preview
    • Still Image capture
    • Camera controls via IOCTLs
  • Sample application with source Code for Linux:
    • Video Preview
    • Still Image capture at selected sensor modes (eCAM_argus_camera)
  • Camera Controls
    • Exposure (both manual and automatic)
    • Sensor Gain
    • Exposure Time
    • Frame Rate
    • Sensor Mode Index

Please contact sales@e-consystems.com for any customization or porting of camera driver to your requirements.

Download e-CAM22_CUNX - Technical Documents:

 Bullat Arrow  Datasheet

 pdf  e-CAM22_CUNX Datasheet

 pdf  e-CAM22_CUNX Lens Datasheet

 Bullat Arrow  User Manual

 pdf  e-CAM22_CUNX Getting Started Manual

pdf e-CAM22_CUNX Developer Guide

pdf e-CAM22_CUNX Linux App User Manual

pdf e-CAM22_CUNX Gstreamer Usage Guide

pdf e-CAM22_CUNX Release Package Manifest

pdf eCAM_Argus Camera Build and Install Guide

Download Sony® STARVIS™ IMX462 Ultra Low-Light Camera

Kit Contents:

    • e-CAM221_CUMI462_MOD - Full HD MIPI Camera Module with lens
    • Adaptor board
    • Flex Cable (15 cm)
    • Linux Driver & Sample Application
  • Please contact sales@e-consystems.com for any customization or to port camera driver according to your requirements.
