e-CAM234_CUMI662C_MOD is a Full HD ultra-low light HDR camera module based on the Sony® STARVIS™ 2 IMX662 1/2.8" CMOS image sensor. It streams 1080p video at up to 97 fps and delivers exceptional low-light performance with enhanced NIR sensitivity, making it ideal for autonomous vehicles, surveillance systems, and industrial applications.
This camera supports both GigE and MIPI CSI-2 interfaces for seamless integration across platforms. Additionally, it offers low latency of up to 75ms for real-time responsiveness.
IMX662 camera variants are available for various platforms, including Jetson Orin NX/Nano, i.MX8, and IP67-rated GigE models like the SMARTOdin22_PoE_IP67—a cloud-connected, PoE-enabled smart AI camera—offering scalable options tailored to diverse application needs.
Ultra Low light Performance
Superior NIR sensitivity
High Dynamic Range (HDR)
Multi-Interface Support
| Product Name | Interface | Supported Platforms | Max no. of Cameras | Documents | Sample Price | |
|---|---|---|---|---|---|---|
| RouteCAM_CU22_IP67 | GigE | - | 1 |
|
|
|
| SMARTOdin22_PoE_IP67 | GigE | - | 1 | - |
- |
|
| e-CAM212_CUONX | MIPI CSI-2 | NVIDIA Jetson Orin NX / Orin Nano | 1 |
|
- |
|
| e-CAM212_CUiMX8 | MIPI CSI-2 | i.MX8 Processors | 1 |
|
- |
|
Module Feature :
| Module Features | |
|---|---|
| Sensor | Sony® STARVIS™ IMX662 |
| Focus Type | Fixed Focus |
| Resolution | 2.0 MP |
| Chroma | Color |
| Shutter Type | Electronic Rolling Shutter |
| Optical Format | 1/2.8" |
| Output Format | RAW 10-bit/12-bit |
| Pixel Size | 2.9 μm x 2.9 μm |
| Sensor Active Area | 1937H x 1097V |
Key Features :
| Key Features | |
|---|---|
| Frame Rate |
|
| Output format | RAW 10-bit/12-bit |
| Compliance | FCC, RoHS |
Electrical and Mechanical :
| Electrical and Mechanical | |
|---|---|
| Operating Voltage | 3.3V ±5% |
| Operating Temperature Range | -30°C to +70°C |
| Typical Power Consumption (W) |
|
| Size in mm (l x b) |
|
e-CAM20_CUMI662_MOD Documents
