e-CAM137_CUMI1335_MOD - 13MP 4K Camera Module

e-CAM137_CUMI1335_MOD is a high performance, 13 MP 4K camera module with S-Mount lens holder and it has better low light performance. This small form factor 4K camera module is based on 1/3.2” AR1335 CMOS image sensor from ON Semiconductor® and has a dedicated, high-performance Image Signal Processor (ISP) that performs the entire Auto functions like auto white balance, auto exposure control in addition to complete image signal processing pipeline that provides best-in-class images and video.

  • 13MP Colour camera with 4-lane MIPI CSI-2 interface
  • 1/3.2" Optical Form-factor
  • Uncompressed UYVY streaming
  • S-mount interchangeable lens holder for flexibility to choose a lens as per application requirements
  • Maximum Image Transfer Rate : Uncompressed UYVY Output Format
  • Resolutions 4-lane MIPI (TX2/TX1) 4-lane MIPI (Xavier)
    VGA (640X480) 100 fps 100 fps
    HD (1280X720) 72 fps 72 fps
    Full HD (1920x1080) 72 fps 72 fps
    4K Ultra HD (3840x2160) 30 fps 30 fps
    4K Cinema (4096 x 2160) - 28 fps
    13MP (4192 x 3120) 19 fps 19 fps
  • Power consumption of Camera Module Board : 1.10W (Approx)
  • Temperature Range
    1. Operation : -30° to 70° C
  • Small form-factor pluggable camera module with S-mount lens holder
  • 30mm x 30mm size
  • 2x 20-pin SMT Connectors on two sides of the camera module for better mechanical stability
  • RoHS Compliant
  • Launched on: 07 Jun 2018
  • AR1335 - CMOS Image Sensor from ON Semiconductor®
  • 1/3.2-inch CMOS active-pixel digital image sensor
  • 1.1 µm pixel size with advanced BSI technology
  • Interlaced multi-exposure readout enabling High Dynamic Range (HDR) still and video applications
  • Two on-die phase-locked loop (PLL) oscillators for super low noise performance
  • Responsivity: 4700 e-/lux-sec
  • Dynamic Range: 69 dB
  • SNR MAX:37 dB
  • 4-lane MIPI CSI-2 interface for video and I2C interface for camera configuration
  • Dual 20-pin connector on board to plug in to customer boards directly
  • Interlaced multi-exposure readout enabling High Dynamic Range (HDR) still and video applications
  • Linux V4L2 Capture demo application
  • Customers can purchase the driver source code from e-con Systems and port the same to their application processor.
  • Please contact sales@e-consystems.com for customization requirements.

Download e-CAM137_CUMI1335_MOD Documents:

pdf e-CAM137_CUMI1335_MOD - 13MP 4K Camera Module Datasheet

Download Evaluation Kit (e-CAM130_CUXVR) Documents:

pdf e-CAM130_CUXVR - 13 MP MIPI NVIDIA® Jetson Xavier Camera Board

Download Evaluation Kit (e-CAM130_TRICUTX2) Documents:

pdf e-CAM130_TRICUTX2 - 13 MP MIPI NVIDIA® Jetson TX2 Camera Board

Evaluation Kit:

1a. ARM Based Solution (NVIDIA® Jetson Xavier Dev Kit)

e-CAM130_CUXVR - Multiple Camera Board for Jetson AGX Xavier (Requires NVIDIA® Jetson Xavier Developer Kit):

The MIPI Camera daughter card (e-CAM130_CUXVR) can be bought by customers choosing to evaluate the e-CAM137_CUMI1335_MOD camera solution with a direct interface on the NVIDIA® Jetson Xavier Developer Kit.

US$349
Buy Camera online

Excluding Shipment Charges

1b. ARM Based Solution (NVIDIA® Jetson TX2/TX1 Dev Kit)

e-CAM130_TRICUTX2 - 4K Multi-Camera System (TRICAM) (Requires NVIDIA® Jetson TX2/TX1 Developer Kit):

The MIPI Camera daughter card (e-CAM130_TRICUTX2) can be bought by customers choosing to evaluate the e-CAM137_CUMI1335_MOD camera solution with a direct interface on the NVIDIA® Jetson TX2/TX1 Developer Kit.

US$749
Buy Camera online

Excluding Shipment Charges

Customers interested in customizing the same camera module or planning to use a different camera/sensor module can contact sales@e-consystems.com and explain their requirement.
