Nedu4CAM88 - 4K 140dB HDR IP67 FPD-Link IV camera module

• Key features:
• • Frame rate: 4k @ 30fps, Full HD @ 30 fps
    Refer Datasheet for complete frame rate details.
  • Output format: UYVY
  • S-mount IP67 compliant lens focused and glued at factory
  • Lightweight, versatile, and portable design
• Interface:
• • Interface: FPD-Link IV
  • Connector: FAKRA connector
  • Cable Length: upto 10m
• Module Features:
• • Sensor: OX08B40 from OmniVision
  • Focus Type: Fixed focus
  • Sensor Resolution: 8.3MP
  • Chroma: Color
  • Shutter Type: Electronic Rolling Shutter
  • Optical Format: 1/1.73"
  • Output Format: UYVY
  • Pixel Size: 2.1μm x 2.1μm
  • Sensor Active Area: 3840(H) x 2160(V)
  • Dynamic Range: Max upto 140 dB
  • Holder: M12 (S-Mount)
  • FOV:
    • Narrow angle: 68.23°(H), 38.83°(V), 80.22°(D) (with the lens provided by econ)
    • Wide angle: 120.12°(H), 67.04°(V), 137.36°(D)
• Electrical & Mechanical:
• • Operating Voltage: 12V +/- 5%
  • Operating Temperature Range: -40°C to 85°C
  • Typical power consumption: 2.4W (for 12V power)
  • Size in mm (l x b):
    • Camera module: 42 x 42 mm
    • Deserializer board: To be purchased separately from TI
• Miscellaneous:
• • Compliance: RoHS

Nedu4CAM88 - Customization:

e-con provides customization, development and porting services for the following requirements:

• IP rated (IP69K) enclosure and IP rated (IP69K) cables for rugged applications.
• Length of the co-axial cable
• Change of lens to meet your FOV and other requirements
• Support for other NVIDIA® Jetson™ platforms as well as carrier boards from other vendors built using NVIDIA platforms
• Support for other processor platforms
• Camera and features customization based on specific requirements. Please contact camerasolutions@e-consystems.com for customization requirements.
