Video Capture Issues with Windows 10 Anniversary edition (2016) Update

As Microsoft recently rolled out the Windows 10 Anniversary Update for the Windows 10 OS, some of the FOURCC formats in the Video Capture layer have been removed. Find out how it affects e-con Systems’ See3CAM USB 3.0 cameras and how to successfully overcome this challenge.

Video Capture Issues with Windows 10 Anniversary
Oct 06, 2016: See3CAM with “Windows 10 Anniversary edition” will work NOW only after

Cumulative Update for Windows 10 Version 1607

Recently Microsoft rolled out a update for the Windows 10 OS which is called Windows 10 Anniversary Update. In this update Microsoft has removed the support for below FOURCC formats in Video Capture layer. So in both the DirectShow and Media Foundation Framework this is not possible to access it.

  • BY8(FOURCC)
  • BY10(FOURCC)
  • Y800(FOURCC)
  • Y16(FOURCC)
  • MJPEG(FOURCC)
  • H.264(FOURCC)

To say it simple in this update we cannot see any of the above formats in the application framework.

Only format supported through DirectShow and Media Foundation is YUY2/NV12.

How this affects See3CAM Users?

Most of our See3CAM uses custom formats, which will not work with this Windows 10 update. They will not be able to see this formats getting displayed in our e-CAMView software.

For these reasons, we recommend our customers not to update the system with this Anniversary Version, Windows 10 version 1607 (OS Build 14393.10 ‘anniversary).

Customers who were using only the YUY2 formats will be able to use the camera as is without any issue.

Microsoft is Working on Update:
Many have reported this issue in the Microsoft Forum and Microsoft has accepted these issues and are working towards a update with the fix for enabling the MJPEG format.

Most likey, for MJPEG format the update would roll out in September and for other custom formats support it will take some time for them to do internal test and will roll out later.

Workaround
Some of the guys have found the workaround to get the webcam with MJPEG working with a registry hack in the anniversary update

http://www.howtogeek.com/267946/how-to-stop-your-webcam-from-freezing-and-crashing-on-windows-10/

The above link is applicable for e-CAMVIew as well, for cameras supporting MJPG formats.

The See3CAM cameras like See3CAM_12CUNIR, See3CAM_CU40, See3CAM_CU51 and See3CAM_10CUG(Color) supporting custom formats BY8 and Y16, please write to camerasolutions@e-consystems.com to get the e-CAMVIew with these format supported.

Here is a related link, where the problems are discussed in detail

https://social.msdn.microsoft.com/Forums/windowsdesktop/en-US/9d6a8704-764f-46df-a41c-8e9d84f7f0f3/mjpg-encoded-media-type-is-not-available-for-usbuvc-webcameras-after-windows-10-version-1607-os?forum=mediafoundationdevelopment

Oct 06, 2016: See3CAM with “Windows 10 Anniversary edition” will work NOW only after

Cumulative Update for Windows 10 Version 1607
