| PCB Design |
PCB Design and Fabrication is the first milestone in realizing the Product concept. e-con Systems has extensive experience in the following areas of PCB Design
- High-speed Board Design
- Expertise in controlling the EMI through layout techniques
- EMI/EMC compliant placement/routing techniques
- Standards compliant layout design for various BUS/Interface standards
- High-speed Differential Signal routing in PECL, LVPECL, CML, LVDS
- On-board Differential traces up to 2.5Gbps
- Controlled Impedance traces with effective termination placements, and also Capability to design for PCB Fabrication Process tolerances
- Mixed-Signal lay-out techniques
- Selection of PCB Dielectric materials (FR4, FR5, BT, Rogers, Teflon) for high-speed controlled impedance boards at OC192 bandwidths
- Trace geometry calculation for controlled impedance boards with co-ordination with PCB Fabrication team to accommodate any differences during processing
- Pre-layout and Post-layout SI Analysis
|
| |
|
|
