Board Design Flow

The Board Design team follows a well-defined process and its output at every critical stage is reviewed. The Board design team interacts closely with the Software and PCB Layout team on critical issues where a co-ordination among these teams is absolutely necessary...

Board Design Flow

Board Design

e-con hardware team has developed profound expertise in the following major areas of Hardware Board Design

bullatHigh-Speed Digital Design with SI Analysis

bullatHigh Efficiency, Robust Power Supply Design

bullatLow Noise Design with Mixed-Signal Integration

bullatHigh-Speed Differential Data Design at OC48/OC192 levels

bullatComponent Engineering for DFM & DVM

bullatLow Power Design Capability

The customers can leverage the e-con expertise in the above areas for faster and efficient product development. The specific areas of expertise of e-con Hardware team are

Processor Architectures

bullatPXA270, PXA320, DM3730, AU1250, X86, ARM, StrongARM* (intel announced EOL for StrongARM SA1110), PowerPC (G3, G4), ColdFire, iMX

bullatIntel IXP/IXC/IXF series of Network processors and AMCC, PMC-Sierra SONET/SDH chipsets

Communication and Buses

bullatUART, IrDA, I2C, I2S, USB (1.1 and 2.0 HighSpeed), IEEE1394, Bluetooth, IR, Legacy  Peripherals and Custom interfaces for devices like RFID Reader/Writer, IR Keyboard etc.

bullatPCI (32b/64b@33/66MHz), PCI-X, cPCI, VME, IDE, SCSI, iSCSI, PCMCIA, SDIO.

bullatCCIR601, CCIR656

High-Speed Communication Interfaces

bullatGMII, XGMII, XAUI, POS-PHY Level3, POS-PHY Level4, SPI-4, SFI-4.

Networking/Communication Interfaces

bullatSONET/SDH, POS, GbE, 10GbE.

Memory Device Interfaces

bullatFlash, SDRAM, DDR-SDRAM.

bullatDiskOnChip, CompactFlash.

Power Supply

bullatLow Noise Switching Power supplies, LDO Regulator designs.
